Adjustable LED power supply 150W 24V constant voltage Driver IP20
Soft start to full brightness and a DIP Switch to choose your favourite brightness adjustment from 4 preset levels (40%, 60%, 80%, 100%) and turn on or off fading/soft start/soothing. A preset light level can be set, to which the LED driver will always return to when lights are switched ON
Adjustable non dimmable LED Driver suitable for 24V LED Strips of total power consumption up to 150W.
It is recommended to calculate 20% more than the tape power consumption to cover losses of the circuit and efficiency of the power supply.
Note: This is high efficiency economy series LED driver. If you prefer lower in-rush current and higher power factor products, then consider our premium series drivers instead. Installers should be aware of in-rush current and the type of MCB required in such cases. (If soft Start DIP switch is ON will reduce inrush current).
LED Driver 150W/24V - Suitable for LED Strips
Input: 175~264V AC (50/60 Hz)
Output: 24V / 6.25 Amps
Ripple & Noise: ≤240mV
Power factor: PF>0.6
Efficiency (typ.): 84%
Inrush current(typ.): Cold start 55A at 240Vac
Leakage current: Max. 0.5mA
Protection: short circuit/over load/over voltage/over temperature
Rating: IP20 (Non-Waterproof)
Dimensions: 195x48x25mm (LxWxH)
Weight: 294g
Warranty offered for the LED driver is 3 years
IMPORTANT NOTICE!
This device should be installed by a qualified electrician in accordance with the latest edition of the IEE Wiring Regulations and any applicable Building Regulations.
