This 100 Watt 24V hybrid dimmable LED driver is optimised for perfect performance with trailing edge dimmers but is also fully compatible with leading edge dimmers. Suitable for dimming 24V LED strips, it can be controlled through either a standard 240V AC wall dimmer switch or 0/1-10 Volts dimming systems. It can also function as a simple on/off switch.
PWM frequency 3500 Hz
It can operate with load ranging from 5% to 100% and the dimming range will be from less then 3% to 100%.
This dimmable driver can operate with trailing edge mains wall dimmer switches, 0/1-10V dimming systems or potentiometer.
We tested this dimmable driver with Lightwave smart dimmer & Varilight V-Pro series and it is compatible.
Compatible with Lutron Grafik Eye System and while we cannot guarantee compatibility with all other Lutron Systems, it is highly likely that it will work seamlessly with them as well.
If you're considering a specific dimmer switch and are unsure about compatibility, we strongly recommend testing as the most reliable approach, especially for mains dimming which is not a standardised protocol. For 0/1-10V or resistance-based systems, compatibility is generally less of a concern. For any further queries, assistance, or to provide feedback, please don't hesitate to email us.
5 Years Warranty
Dims: 27.5cm x 4.5cm x 2.5
IMPORTANT NOTICE!
This device should be installed by a qualified electrician in accordance with the latest edition of the IEE Wiring Regulations and any applicable Building Regulations.
