WZ5 ZigBee & RF 2.4GHz 5-in-1 LED Controller | Tuya Compatible

The WZ5 is a ZigBee & 2.4GHz RF LED controller for smart lighting systems. It supports single-colour, CCT, RGB, RGBW, and RGB+CCT LED strips. Use it with a ZigBee hub like WG-Z, Philips Hue, or Tuya for full app and voice control, or pair it with Hi-Line RF remotes and panels for local wireless control. A flexible choice for smart and manual setups alike.

HL-WZ5

Require more quantity?

We have 25 in stock ready to dispatch. If you require more, this product is also available to preorder with an estimated delivery timeframe of 30-45 days.
25 Items In stock
Next working day delivery
£30.00
36.00
with VAT)
VAT excluded



The WZ5 ZigBee & RF 2.4GHz LED Controller from Hi-Line Lighting offers unparalleled versatility, seamlessly bridging the gap between ZigBee-based smart home systems and Hi-Line's RF (Radio Frequency) product range. Designed to simplify LED control and provide maximum flexibility, this controller is ideal for both residential and commercial lighting installations.


Key Features

  • 5-in-1 Control Capability: Supports single-colour, dual-colour (CCT), RGB, RGBW, and RGB+CCT LED strips, making it a universal controller for varied lighting installations.
  • ZigBee Integration: Fully compatible with ZigBee 3.0, seamlessly connecting to hubs like Philips Hue Bridge, Tuya ZigBee Gateway, and Amazon Echo devices with ZigBee.
  • RF Functionality (Hi-Line Only): Pairs with Hi-Line’s 2.4GHz RF remotes, touch panels, and dimmers for additional manual control. Only Hi-Line’s RF 2.4GHz products are supported; third-party RF accessories are not compatible.
  • Tuya App Control: Pair with the Tuya ZigBee Gateway for full control via the Tuya Smart app, enabling lighting adjustments and integration with other smart devices for a complete smart home ecosystem. (You DO need a ZigBee hub (e.g. WG-Z) to control the WZ5 via Tuya Smart Life, Alexa, Google, or for app-based automation).
  • ZigBee-to-RF Conversion: Acts as a ZigBee-to-RF converter, allowing one ZigBee controller to synchronise multiple RF devices through the Tuya Smart app, extending control range and scalability.

Technical Specifications

  • Input Voltage: 12–24VDC
  • Output Channels: 5CH, 3A per channel (Constant Voltage)
  • Control Distance: ZigBee up to 15m; RF 2.4GHz up to 30m (obstacle-free)
  • Dimming: Smooth 4096-level dimming with logarithmic curve
  • PWM Frequency: 1000Hz default
  • Certifications: CE, UKCA, EMC
  • Protection Features: Reverse polarity, over-heat, and short-circuit protection
  • Operating Temperature: -30°C to +55°C
  • Weight & Dimensions: 0.055kg; 120 x 43 x 27mm
  • Warranty: 3 years standard, extendable to 5 years with our extended warranty option

Additional Information

  • Matching Accessories: Find compatible accessories, such as Hi-Line 2.4GHz RF remotes, wall touch panels, and dimmers, in the ‘Related Products’ tab. These accessories are specifically designed to work seamlessly with the WZ5.
  • Attachments Tab: Visit the ‘Attachments’ tab for detailed datasheets, user manuals, and other technical documents to ensure a smooth installation process.

Why Choose WZ5 over WZS5 or WT5?

  • ZigBee with RF Support: Unlike the WZS5 (ZigBee-only) or WT5 (RF and WiFi only), the WZ5 combines the two, offering maximum compatibility and functionality in one device.
  • Hi-Line RF Integration: For installations requiring RF remotes or wall panels alongside ZigBee integration, the WZ5 is the perfect choice.
  • Versatility for Upgrades: Designed to accommodate lighting upgrades and dual-system installations, reducing the need for additional devices.

Who Should Buy This Controller?

  • Installers: Perfect for installations requiring both ZigBee smart home integration and RF remote control for local operation.
  • Smart Home Enthusiasts: Ideal for users with Philips Hue or Tuya systems looking for added RF functionality with Hi-Line accessories.
  • Large-Scale Projects: Excellent for multi-zone or wide-range installations where ZigBee-RF conversion and RF range extend usability.

Notes

  • Ensure all connected RF accessories are Hi-Line’s 2.4GHz range.
  • ZigBee functionality works universally with certified ZigBee devices, while RF compatibility is proprietary to Hi-Line products.

The WZ5 bridges ZigBee's industry-standard protocol with Hi-Line’s advanced RF 2.4GHz capabilities, offering a powerful solution for versatile lighting installations. This makes it a standout option for both smart home enthusiasts and professional installers. For advice or assistance, our team is ready to help.

Important Compatibility Note:
This controller is Zigbee + RF (2.4GHz) and works in two ways:

  1. No hub needed – local wireless control:
    If you don’t plan to use Alexa, Google, or any smart app, this controller works perfectly on its own with our 2.4GHz RF remote controls and touch wall panels. No internet or Zigbee hub is needed — ideal for simple wireless lighting setups.

  2. Smart app or voice control – Zigbee hub required:
    To control this product via the Tuya Smart Life app, or to use Alexa, Google Assistant, or Philips Hue, you will need a Zigbee hub. Compatible options include:
    WG-Z Tuya Zigbee Gateway (recommended for Tuya integration)
    Amazon Echo 4th Gen, Echo Studio, Echo Show 10 (with built-in Zigbee)
    Philips Hue Bridge (for integration with the Hue ecosystem)

  3. Looking for WiFi control without a hub?
    If you prefer direct WiFi connection without using a Zigbee hub, check our WT5 Controller. It connects directly to your Tuya Smart Life app and also works with Alexa and Google Assistant — no gateway required.

What does the WG-Z Zigbee Gateway do, and why choose WZ5 over WT5?
The WG-Z connects Zigbee devices like this controller to your WiFi network, enabling control through the Tuya Smart Life app and voice assistants.
Zigbee-based setups (like WZ5 + WG-Z) form a mesh network that offers improved range, faster response, and greater reliability — especially when controlling many devices across multiple zones.
The WG-Z supports up to 128 devices in one system, making it ideal for large smart home or commercial installations.

Brand
Hi-Line
Type
RGB-CCT Tunable
RGB/RGBW controller
Single colour controller
Tunable white (CCT)
Voltage
12-24V DC
Voltage Type
Constant Voltage
Type of control
Phone and tablet (WIFI)
Radio Frequency (RF)
ZigBee
Operating Frequency (RF)
2.4GHz
Controller Type
Hybrid Zigbee
